Differential Crystal Oscillator Output Type : LVDS. Output frequencies 25MHz ~ 200MHz. Excellent low phase noise and jitter. Tri-state function available. Applications : Fibre Channel , Gigabit Ethernet , Serial ATA , Serial Attached SCSI , PCI-Express, SDH / SONET , Telecom , Networking , Server , Storage , Instrument. RoHS compliant / Pb Free.
Product Details
Crystal Oscillator Parameters
| ITEMS/TYPE | X3D |
| Frequency Range | 25 ~ 200 MHz |
| Output Type | LVDS |
| Oscillation Mode | Fundamental / 3rd Overtone |
| Output Load | 100Ω |
| Supply Voltage (VDD) | 2.5V, 3.3V |
| Total Frequency Stability | ±50ppm , or specify |
| Operating Temperature Range | - 40~+85℃, or specify |
| Storage Temperature Range | - 55~+125 ℃ |
| Voltage Vol ( Max.) / Voh ( Min.) | VDD - 1.62 V / VDD - 1.025 V |
| Rise ( Tr ) / Fall ( Tf )Time(20 %~80 %) | 1nS Max. |
| Supply Current | 80mA Max. |
| Symmetry | 45~55 % |
| Start-up Time | 10mS Max. |
| Phase Jitter ( 12 KHz ~ 20 MHz ) | 1pS Max. |
